• Dispense 1 to 8 different reagents simultaneously. Each reagent dispensed is controlled independently.

  ---

• Dispense rate set digitally from 0.01 uL/mm to 10 uL/mm.

  ---

• Carriage speed set digitally from 10 to 300 mm/second.

  ---

• Dispense onto membranes up to 500 mm long and 120 mm wide.

  ---

• Completely digital operation. No micrometers or pressure regulators required.

  ---

• Minimum spacing between nozzles is 5 mm (standard), 2.5 mm with custom designs.

  ---

• Internal vacuum source to hold down membrane.

  ---

• Low dead volume - approximately 100 uL of which 60 uL can be recovered when dispensing is complete.

  ---

• Universal Power Supply - 100-240VAC 50/60Hz, 150 watts.

  ---

• Small foot print (33 cm wide by 66 cm long) and light weight (13 kg).
